Description
The Mikro 70cc kid’s quad bike is our top selling kids quad and represents excellent value for money. Safety is paramount, reliability is excellent and a full range of spare parts are available off the shelf at all times. The great benefit of the Orion Mikro quad is a fully automatic gearbox which features the proven ‘rev & go’ system which is very easy for children to use.
This quad features and easily adjustable speed limiter with a variable top speed of approx. 12 – 30mph. The speed limiter is mounted on the handlebar and can be adjusted in a few seconds with a simple tool. The quad is also fitted with a very low noise, high quality four stroke engine (just like a car) so no messy oil mixing is required!
Unlike some other makes, the VRX70 has both front and rear suspension for better cornering and a more comfortable ride. The front and rear brakes are operated by easily accessible levers on the handlebar so there is no complicated foot brake to worry about.
Key Machine Features –
- Push button electric start
- Remote safety cut off
- Wide axles & low centre of gravity for added stability
- Front & rear brakes
- Easy access choke lever for cold start days
- Chunky off road tyres
- 12 Month main parts warranty & full spare parts back up
Product Specifications
| WEIGHT | 73KG |
|---|---|
| GROUND CLEARANCE | 80MM |
| DIMENSIONS | LENGTH = 1080MM / WIDTH = 680MM / HEIGHT = 800MM |
| SEATS | SINGLE CAPACITY CUSHIONED SEAT (SEAT HEIGHT = 580MM) |
| AXLE | WIDE AXLE FOR STABILITY |
| FRAME | QUALITY CHROMOLY FINISH |
| TYRES | FRONT / REAR = 145 X 70 – 6 OFF ROAD PATTERN |
| BRAKES | FRONT DRUM BRAKES / REAR HYDRAULIC CALIPER + REAR BRAKE DISC |
| WHEELS | BLACK COATED STEEL RIMS – 6” FRONT & 6” REAR |
| SUSPENSION | INDEPENDENT WISHBONES FRONT / SINGLE SWING ARM – SOLID AXLE REAR |
| SHOCK ABSORBERS | FRONT INDEPENDENT SHOCKS / REAR MONO SHOCK |
| FINAL DRIVE | SOLID REAR AXLE |
| DRIVE | CHAIN DRIVE – WITH CHAIN GUARD |
| TRANSMISSION | FULLY AUTOMATIC – TORQUE CONVERTOR – NO GEARS |
| OIL | 10W/40 (NO FUEL / OIL MIXING IS REQUIRED) |
| FUEL / CAPACITY | STANDARD 4 STROKE PETROL / 2.3L FUEL TANK CAPACITY |
| COOLING | AIR COOLED |
| START | PUSH BUTTON – ELECTRIC KEY START (REMOVABLE FOR SAFETY) |
| TOP SPEED | 8 – 25MPH+ (FULLY RESTRICTABLE) |
| CHOKE | INCLUDED EASY ACCESS LEVER (FOR COLD START DAYS) |
| MODEL | APOLLO ORION |
| ENGINE | 70CC – SINGLE CYLINDER – PZ19 CARBURETOR |
